How to center text in TASM?

Centering Text in TASM: A Guide for x86 DOS Assembly

Learn how to precisely center text on the screen in TASM (Turbo Assembler) for x86 DOS environments, covering basic principles and practical code examples.

Centering text in a console application might seem trivial in high-level languages, but in x86 DOS assembly using TASM, it requires a direct understanding of screen memory, cursor positioning, and string manipulation. This guide will walk you through the necessary steps and provide a complete code example to achieve perfectly centered text on your DOS screen.

Understanding the DOS Screen and Cursor

In DOS, the screen is typically a text-mode display, often 80 columns wide and 25 rows high. Each character position has a corresponding memory location. To center text, we need to know the screen's width and the length of the string we want to display. The cursor's position is controlled using BIOS interrupts or direct video memory access. For simplicity and compatibility, we'll primarily use BIOS interrupt INT 10h for cursor control.

flowchart TD
    A[Start]
    B{Get Screen Width}
    C{Get String Length}
    D[Calculate Start Column]
    E[Set Cursor Position]
    F[Display String]
    G[End]

    A --> B
    B --> C
    C --> D
    D --> E
    E --> F
    F --> G

Flowchart for Centering Text Logic

Calculating the Starting Column

The core of centering text lies in calculating the correct starting column. If the screen is SCREEN_WIDTH characters wide and your string is STRING_LENGTH characters long, the number of empty spaces on either side of the string will be (SCREEN_WIDTH - STRING_LENGTH) / 2. This value gives us the starting column for our centered text. Remember that screen columns are usually 0-indexed.

; Assume SCREEN_WIDTH = 80, STRING_LENGTH = 15
; Calculation: (80 - 15) / 2 = 65 / 2 = 32 (integer division)
; Starting column = 32

MOV AX, SCREEN_WIDTH
SUB AX, STRING_LENGTH
MOV CX, 2
DIV CX ; AX now holds the starting column

Assembly snippet for calculating the starting column.

Full TASM Example for Centering Text

This example demonstrates a complete TASM program that defines a string, calculates its length, determines the starting column, sets the cursor, and displays the string centered on the screen. It uses INT 10h for cursor positioning and INT 21h for string output.

.MODEL SMALL
.STACK 100h

.DATA
    myString DB 'Hello, TASM World!', 0
    stringLength DW ?
    screenWidth DW 80 ; Standard 80-column screen
    screenHeight DW 25 ; Standard 25-row screen
    targetRow DB 12 ; Row to center the text on (0-indexed)

.CODE
MAIN PROC
    MOV AX, @DATA
    MOV DS, AX

    ; Calculate string length
    MOV SI, OFFSET myString
    MOV CX, 0
    countLoop:
        CMP BYTE PTR [SI], 0
        JE endCount
        INC CX
        INC SI
        JMP countLoop
    endCount:
    MOV stringLength, CX

    ; Calculate starting column
    MOV AX, screenWidth
    SUB AX, stringLength
    MOV BX, 2
    DIV BX ; AX now contains the starting column
    MOV DH, targetRow ; Row (0-indexed)
    MOV DL, AL        ; Column (0-indexed)
    MOV BH, 0         ; Page number (usually 0)

    ; Set cursor position (INT 10h, AH=02h)
    MOV AH, 02h
    INT 10h

    ; Display the string (INT 21h, AH=09h)
    MOV DX, OFFSET myString
    MOV AH, 09h
    INT 21h

    ; Wait for a key press before exiting
    MOV AH, 01h
    INT 21h

    ; Exit to DOS
    MOV AH, 4Ch
    INT 21h
MAIN ENDP
END MAIN

Complete TASM program to center a string on the screen.

1. Define Your String

Declare your string in the .DATA segment, ensuring it's null-terminated (e.g., DB 'My Text', 0).

2. Calculate String Length

Write a loop to iterate through your string until the null terminator is found, incrementing a counter to get the length. Store this length in a variable.

3. Determine Screen Dimensions

For standard text modes, assume 80 columns and 25 rows. If you need dynamic detection, you can use INT 10h, AH=0Fh to get video mode information.

4. Calculate Starting Column

Use the formula (screenWidth - stringLength) / 2 to find the 0-indexed starting column. Store the result in DL for cursor positioning.

5. Set Cursor Position

Load the desired row into DH and the calculated column into DL. Set BH to 0 (for video page 0). Call INT 10h with AH=02h.

6. Display the String

Load the offset of your string into DX. Call INT 21h with AH=09h to print the null-terminated string.
