Does using "new" on a struct allocate it on the heap or stack?

C# Structs: Heap vs. Stack Allocation with 'new' Keyword

Demystify C# struct allocation. Understand when 'new' allocates structs on the stack, heap, or neither, and the implications for memory management and performance.

In C#, the new keyword is commonly associated with allocating objects on the heap. However, when it comes to struct types, its behavior can be a source of confusion. This article clarifies whether using new on a struct allocates it on the heap or the stack, and explores the underlying memory management principles.

Understanding Value Types and Reference Types

Before diving into struct allocation, it's crucial to differentiate between value types and reference types in C#.

• Value Types: Directly contain their data. Examples include int, bool, float, and structs. They are typically allocated on the stack where they are declared (e.g., local variables, method parameters) or inline within a containing object (e.g., a field in a class).
• Reference Types: Store a reference (memory address) to their data, which is allocated on the heap. Examples include classes, strings, and arrays. The variable itself holds the reference, while the actual object data resides on the heap.

The 'new' Keyword with Structs

When you use the new keyword with a struct, it primarily serves to call a constructor and initialize the struct's fields. It does not inherently dictate heap allocation for the struct itself. The actual memory location (stack or heap) depends on where the struct instance is declared or used.

Consider the following scenarios:

flowchart TD
    A[Struct Declaration] --> B{Where is it declared?}
    B -->|Local Variable in Method| C[Allocated on Stack]
    B -->|Field of a Class| D[Allocated on Heap (as part of class instance)]
    B -->|Field of another Struct| E[Allocated inline within parent struct (stack or heap based on parent)]
    B -->|Method Parameter| F[Allocated on Stack (copy passed by value)]
    C --> G["new" calls constructor, initializes fields]
    D --> G
    E --> G
    F --> G

Memory Allocation Flow for C# Structs with 'new'

Scenario 1: Local Variable Structs

When a struct is declared as a local variable within a method, it is typically allocated on the stack, regardless of whether new is used. The new keyword simply ensures that the struct's constructor is called to initialize its fields.

public struct Point
{
    public int X { get; set; }
    public int Y { get; set; }

    public Point(int x, int y)
    {
        X = x;
        Y = y;
    }
}

public class Program
{
    public static void Main()
    {
        // Allocated on the stack
        Point p1 = new Point(10, 20);
        Console.WriteLine($"p1: ({p1.X}, {p1.Y})");

        // Also allocated on the stack, default constructor called implicitly
        Point p2;
        p2.X = 5;
        p2.Y = 15;
        Console.WriteLine($"p2: ({p2.X}, {p2.Y})");
    }
}

Local struct allocation on the stack

Scenario 2: Structs as Fields in a Class

If a struct is a field within a class, then the struct instance will be allocated on the heap as part of the containing class instance. The new keyword, if used in the class's constructor or field initializer, will still call the struct's constructor, but the memory for the struct itself is part of the heap-allocated class object.

public class Circle
{
    public Point Center; // Point is a struct
    public int Radius { get; set; }

    public Circle(int centerX, int centerY, int radius)
    {
        // 'new Point' calls the struct constructor
        // The 'Center' struct is allocated on the heap, as part of the Circle object
        Center = new Point(centerX, centerY);
        Radius = radius;
    }
}

public class Program
{
    public static void Main()
    {
        // Circle object is on the heap, and its 'Center' struct field is part of that heap allocation
        Circle c = new Circle(0, 0, 5);
        Console.WriteLine($"Circle Center: ({c.Center.X}, {c.Center.Y})");
    }
}

Struct field allocation within a class on the heap

Scenario 3: Structs as Fields in Another Struct

When a struct contains another struct as a field, the inner struct is allocated inline within the outer struct. Its ultimate location (stack or heap) then depends on where the outer struct is allocated.

public struct Rectangle
{
    public Point TopLeft; // Point is a struct
    public Point BottomRight; // Point is a struct

    public Rectangle(int x1, int y1, int x2, int y2)
    {
        // 'new Point' calls constructors
        // TopLeft and BottomRight structs are allocated inline within the Rectangle struct
        TopLeft = new Point(x1, y1);
        BottomRight = new Point(x2, y2);
    }
}

public class Program
{
    public static void Main()
    {
        // Rectangle struct is allocated on the stack
        // TopLeft and BottomRight are also on the stack, nested within Rectangle
        Rectangle rect = new Rectangle(0, 10, 20, 0);
        Console.WriteLine($"Rectangle TopLeft: ({rect.TopLeft.X}, {rect.TopLeft.Y})");
    }
}

Nested struct allocation
