How to align ImageView to the bottom, fill its width and height, and keep its aspect ratio?

Aligning an ImageView to the Bottom, Filling Width, and Maintaining Aspect Ratio in Android

Learn how to correctly position an ImageView at the bottom of its parent, make it fill the available width and height, and preserve its original aspect ratio in Android layouts.

Achieving specific layout behaviors for ImageView components in Android can sometimes be tricky, especially when combining multiple requirements like aligning to the bottom, filling parent dimensions, and preserving the aspect ratio. This article will guide you through the necessary XML attributes and their interactions to achieve this precise layout for your ImageView.

Understanding the Core Attributes

To fulfill the requirements, we need to leverage several key attributes of the ImageView and its parent layout. The primary attributes involved are android:layout_width, android:layout_height, android:layout_alignParentBottom, and android:scaleType. Each plays a crucial role in defining the final appearance and positioning of the image.

flowchart TD
    A[ImageView Requirements] --> B{Fill Width?}
    B -- Yes --> C[android:layout_width="match_parent"]
    B -- No --> D[android:layout_width="wrap_content" or fixed dp]

    A --> E{Fill Height?}
    E -- Yes --> F[android:layout_height="match_parent"]
    E -- No --> G[android:layout_height="wrap_content" or fixed dp]

    A --> H{Align Bottom?}
    H -- Yes --> I[android:layout_alignParentBottom="true"]
    H -- No --> J[Other alignment options]

    A --> K{Maintain Aspect Ratio?}
    K -- Yes --> L[android:scaleType="centerCrop" or "fitXY" + adjustViewBounds]
    K -- No --> M[android:scaleType="fitXY" (without adjustViewBounds)]

    C & F & I & L --> N[Combined Solution]

Decision flow for ImageView layout attributes

Implementing the Solution with RelativeLayout

A RelativeLayout is often the most straightforward choice for positioning views relative to each other or to the parent container. To align the ImageView to the bottom and make it fill the width and height while maintaining its aspect ratio, we'll combine layout_width="match_parent", layout_height="match_parent", layout_alignParentBottom="true", and scaleType="centerCrop" or scaleType="fitCenter" with adjustViewBounds="true".

<RelativeLayout
    xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="match_parent"
    android:layout_height="match_parent">

    <ImageView
        android:id="@+id/my_image_view"
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        android:layout_alignParentBottom="true"
        android:scaleType="centerCrop"
        android:src="@drawable/my_background_image" />

</RelativeLayout>

XML layout for an ImageView aligned to the bottom, filling width/height, and using centerCrop.

Alternative: scaleType="fitCenter" with adjustViewBounds="true"

If you prefer to see the entire image and are willing to have empty space (letterboxing/pillarboxing) around it if the aspect ratios don't match, you can use scaleType="fitCenter" in conjunction with adjustViewBounds="true". This combination ensures the image is scaled down to fit within the ImageView while preserving its aspect ratio, and the ImageView itself will adjust its bounds to match the image's aspect ratio if possible, given the match_parent constraints.

<RelativeLayout
    xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="match_parent"
    android:layout_height="match_parent">

    <ImageView
        android:id="@+id/my_image_view_fit"
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        android:layout_alignParentBottom="true"
        android:scaleType="fitCenter"
        android:adjustViewBounds="true"
        android:src="@drawable/my_background_image" />

</RelativeLayout>

XML layout using fitCenter and adjustViewBounds to preserve aspect ratio without cropping.
