Archetype for EJB + JBoss7 Porj

Setting Up a JBoss 7 EJB Project with Maven Archetype

Learn how to quickly bootstrap an Enterprise JavaBeans (EJB) project for JBoss 7 using Maven archetypes, streamlining your development workflow.

Developing Enterprise JavaBeans (EJB) applications for JBoss 7 (WildFly) can be significantly simplified by leveraging Maven archetypes. An archetype is a Maven project templating toolkit that allows users to create new projects from a predefined pattern. This article guides you through the process of generating, configuring, and deploying a basic EJB project using a suitable Maven archetype, specifically focusing on JBoss 7 compatibility.

Understanding Maven Archetypes for EJB Projects

Maven archetypes provide a standardized way to create new projects. For EJB development, an archetype typically sets up the basic project structure, pom.xml dependencies for EJB APIs, JBoss-specific configurations, and a sample EJB and client. This saves considerable time compared to manually setting up a project, ensuring best practices and correct dependencies are in place from the start. While many archetypes exist, selecting one that aligns with JBoss 7 (WildFly) and EJB 3.x specifications is crucial.

flowchart TD
    A[Start] --> B{Choose Archetype}
    B --> C[Generate Project]
    C --> D[Configure pom.xml]
    D --> E[Develop EJB]
    E --> F[Build Project]
    F --> G[Deploy to JBoss 7]
    G --> H[Test Application]
    H --> I[End]

Typical EJB Project Development Workflow with Maven Archetype

Generating the EJB Project Archetype

The first step is to use Maven to generate the project from an archetype. We'll use a common archetype that provides a good starting point for EJB 3.1 projects compatible with JBoss AS 7 / WildFly. Open your terminal or command prompt and execute the following Maven command. This command will prompt you for groupId, artifactId, version, and package.

mvn archetype:generate \
    -DarchetypeGroupId=org.codehaus.mojo.archetypes \
    -DarchetypeArtifactId=ejb-javaee6 \
    -DarchetypeVersion=1.0 \
    -DgroupId=com.example \
    -DartifactId=my-ejb-project \
    -Dversion=1.0.0-SNAPSHOT \
    -Dpackage=com.example.ejb \
    -DinteractiveMode=false

Maven command to generate an EJB 3.1 project archetype.

Project Structure and Initial Configuration

After generation, you'll have a new directory named my-ejb-project (or whatever you set as artifactId). Inside, you'll find a standard Maven project structure, including a pom.xml file, src/main/java for your EJB source code, and src/test/java for tests. The pom.xml will already contain the necessary dependencies for EJB 3.1 and Java EE 6. You might need to adjust the JBoss-specific dependencies or plugin versions to align perfectly with your JBoss 7/WildFly version.

<project ...>
    <modelVersion>4.0.0</modelVersion>
    <groupId>com.example</groupId>
    <artifactId>my-ejb-project</artifactId>
    <version>1.0.0-SNAPSHOT</version>
    <packaging>ejb</packaging>

    <properties>
        <project.build.sourceEncoding>UTF-8</project.build.sourceEncoding>
        <maven.compiler.source>1.8</maven.compiler.source>
        <maven.compiler.target>1.8</maven.compiler.target>
        <version.jboss.bom>7.0.0.Final</version.jboss.bom> <!-- Adjust as needed -->
    </properties>

    <dependencyManagement>
        <dependencies>
            <dependency>
                <groupId>org.jboss.spec</groupId>
                <artifactId>jboss-javaee-6.0</artifactId>
                <version>${version.jboss.bom}</version>
                <type>pom</type>
                <scope>import</scope>
            </dependency>
        </dependencies>
    </dependencyManagement>

    <dependencies>
        <dependency>
            <groupId>javax.ejb</groupId>
            <artifactId>ejb-api</artifactId>
            <scope>provided</scope>
        </dependency>
        <!-- Other dependencies like CDI, JPA if needed -->
    </dependencies>

    <build>
        <plugins>
            <plugin>
                <groupId>org.apache.maven.plugins</groupId>
                <artifactId>maven-ejb-plugin</artifactId>
                <version>2.3</version>
                <configuration>
                    <ejbVersion>3.1</ejbVersion>
                </configuration>
            </plugin>
            <!-- JBoss specific plugins for deployment if desired -->
        </plugins>
    </build>
</project>

Example pom.xml snippet for an EJB project, highlighting key configurations.

Developing and Deploying Your EJB

With the project set up, you can now start developing your EJBs. The archetype usually provides a sample StatelessSessionBean and its remote/local interfaces. You can modify these or add new ones. Once your EJB is developed, you can build the project into an EJB JAR and deploy it to your running JBoss 7 (WildFly) instance.

1. Navigate to Project Directory

Open your terminal and change the directory to your newly created project: cd my-ejb-project.

2. Build the EJB JAR

Compile and package your EJB project into a .jar file using Maven: mvn clean install. This will create the EJB JAR in the target/ directory.

3. Deploy to JBoss 7/WildFly

Manually copy the generated EJB JAR (e.g., my-ejb-project-1.0.0-SNAPSHOT.jar) from the target/ directory to the standalone/deployments/ folder of your JBoss 7/WildFly installation. JBoss will automatically detect and deploy the EJB.

4. Verify Deployment

Check the JBoss server logs for successful deployment messages. You should see output indicating that your EJB has been registered and is available.
