Implementing a Video Timer in Android Applications

Hero image for how to add video timer in android

Learn how to add a customizable video timer to your Android applications, enabling features like auto-pause, countdowns, and progress tracking for media playback.

Adding a video timer to an Android application can significantly enhance the user experience. Whether you need to display the remaining time, implement an auto-pause feature after a certain duration, or simply show the current playback position, a well-integrated timer is crucial. This article will guide you through the process of implementing a video timer using Android's MediaPlayer or ExoPlayer and updating the UI in real-time.

Understanding Video Playback and Timers

Before diving into the implementation, it's important to understand how video playback works in Android and how to synchronize a timer with it. Android provides MediaPlayer for basic video playback and ExoPlayer for more advanced, customizable media handling. Both offer methods to get the current position and duration of the media. A timer typically involves periodically querying these values and updating a TextView or a custom progress bar.

sequenceDiagram
    participant User
    participant AndroidApp
    participant VideoPlayer
    participant TimerUI

    User->>AndroidApp: Starts video playback
    AndroidApp->>VideoPlayer: initialize() & play()
    loop Timer Update Loop
        AndroidApp->>VideoPlayer: getCurrentPosition()
        VideoPlayer-->>AndroidApp: current_ms
        AndroidApp->>VideoPlayer: getDuration()
        VideoPlayer-->>AndroidApp: total_ms
        AndroidApp->>TimerUI: updateDisplay(current_ms, total_ms)
        TimerUI-->>User: Shows time (e.g., 0:30 / 2:15)
        AndroidApp->>AndroidApp: Wait for interval (e.g., 1 second)
    end
    User->>AndroidApp: Pauses/Stops video
    AndroidApp->>VideoPlayer: pause()/stop()
    AndroidApp->>TimerUI: stopUpdates()

Sequence diagram for video timer update process

Implementing a Basic Timer with Handler and Runnable

The most common way to implement a periodic timer in Android is by using a Handler and a Runnable. The Runnable will contain the logic to update the timer UI, and the Handler will post this Runnable to be executed repeatedly at a specified interval. This approach ensures UI updates happen on the main thread safely.

import android.os.Handler;
import android.widget.TextView;
import android.media.MediaPlayer;

public class VideoTimer {

    private Handler handler = new Handler();
    private Runnable runnable;
    private MediaPlayer mediaPlayer;
    private TextView timerTextView;

    public VideoTimer(MediaPlayer player, TextView textView) {
        this.mediaPlayer = player;
        this.timerTextView = textView;
        initRunnable();
    }

    private void initRunnable() {
        runnable = new Runnable() {
            @Override
            public void run() {
                if (mediaPlayer != null && mediaPlayer.isPlaying()) {
                    int currentPosition = mediaPlayer.getCurrentPosition();
                    int duration = mediaPlayer.getDuration();
                    timerTextView.setText(formatTime(currentPosition) + " / " + formatTime(duration));
                }
                handler.postDelayed(this, 1000); // Update every 1 second
            }
        };
    }

    public void startTimer() {
        handler.post(runnable);
    }

    public void stopTimer() {
        handler.removeCallbacks(runnable);
    }

    private String formatTime(int milliseconds) {
        int seconds = (milliseconds / 1000) % 60;
        int minutes = (milliseconds / (1000 * 60)) % 60;
        int hours = (milliseconds / (1000 * 60 * 60)) % 24;
        if (hours > 0) {
            return String.format("%02d:%02d:%02d", hours, minutes, seconds);
        } else {
            return String.format("%02d:%02d", minutes, seconds);
        }
    }
}

Java code for a basic video timer using Handler and Runnable.

Integrating the Timer into Your Activity/Fragment

Once you have the VideoTimer class, you need to integrate it into your Activity or Fragment where the video playback occurs. This involves initializing the MediaPlayer or ExoPlayer, setting up your VideoView or PlayerView, and then creating and managing an instance of your VideoTimer.

<!-- activity_main.xml or fragment_video.xml -->
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="match_parent"
    android:layout_height="match_parent">

    <VideoView
        android:id="@+id/video_view"
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        android:layout_centerInParent="true" />

    <TextView
        android:id="@+id/timer_text_view"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_alignParentBottom="true"
        android:layout_alignParentEnd="true"
        android:layout_margin="16dp"
        android:textColor="#FFFFFF"
        android:textSize="18sp"
        android:background="#80000000"
        android:padding="8dp"
        android:text="00:00 / 00:00" />

</RelativeLayout>

Layout XML for VideoView and TextView for the timer.

import android.net.Uri;
import android.os.Bundle;
import android.widget.MediaController;
import android.widget.TextView;
import android.widget.VideoView;
import androidx.appcompat.app.AppCompatActivity;

public class MainActivity extends AppCompatActivity {

    private VideoView videoView;
    private TextView timerTextView;
    private VideoTimer videoTimer;

    @Override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);
        setContentView(R.layout.activity_main);

        videoView = findViewById(R.id.video_view);
        timerTextView = findViewById(R.id.timer_text_view);

        // Set up MediaController for basic playback controls
        MediaController mediaController = new MediaController(this);
        mediaController.setAnchorView(videoView);
        videoView.setMediaController(mediaController);

        // Set video URI (replace with your video source)
        String videoPath = "android.resource://" + getPackageName() + "/" + R.raw.sample_video;
        Uri uri = Uri.parse(videoPath);
        videoView.setVideoURI(uri);

        videoView.setOnPreparedListener(mp -> {
            // Initialize and start the timer once the video is prepared
            videoTimer = new VideoTimer(mp, timerTextView);
            videoTimer.startTimer();
            videoView.start(); // Start playback
        });

        videoView.setOnCompletionListener(mp -> {
            // Stop the timer when video completes
            if (videoTimer != null) {
                videoTimer.stopTimer();
            }
            timerTextView.setText("00:00 / 00:00"); // Reset timer display
        });
    }

    @Override
    protected void onPause() {
        super.onPause();
        if (videoTimer != null) {
            videoTimer.stopTimer(); // Stop timer when activity is paused
        }
    }

    @Override
    protected void onResume() {
        super.onResume();
        if (videoTimer != null && videoView.isPlaying()) {
            videoTimer.startTimer(); // Restart timer if video is playing and activity resumes
        }
    }

    @Override
    protected void onDestroy() {
        super.onDestroy();
        if (videoTimer != null) {
            videoTimer.stopTimer(); // Ensure timer is stopped to prevent memory leaks
        }
        if (videoView != null) {
            videoView.stopPlayback();
        }
    }
}

Integrating the VideoTimer into an AppCompatActivity.

Advanced Timer Features: Auto-Pause and Countdown

Beyond simple progress display, you can extend the timer to implement features like auto-pausing after a set duration or displaying a countdown. This involves adding conditional logic within your Runnable.

public class VideoTimer {
    // ... (previous code)

    private long autoPauseDurationMillis = -1; // -1 for no auto-pause

    public void setAutoPauseDuration(long durationSeconds) {
        this.autoPauseDurationMillis = durationSeconds * 1000;
    }

    private void initRunnable() {
        runnable = new Runnable() {
            @Override
            public void run() {
                if (mediaPlayer != null && mediaPlayer.isPlaying()) {
                    int currentPosition = mediaPlayer.getCurrentPosition();
                    int duration = mediaPlayer.getDuration();

                    // Update display for current/total time
                    timerTextView.setText(formatTime(currentPosition) + " / " + formatTime(duration));

                    // Implement auto-pause logic
                    if (autoPauseDurationMillis != -1 && currentPosition >= autoPauseDurationMillis) {
                        mediaPlayer.pause();
                        stopTimer(); // Stop timer after pausing
                        // Optionally, show a message to the user
                        // Toast.makeText(context, "Video paused after " + formatTime(autoPauseDurationMillis), Toast.LENGTH_SHORT).show();
                    }
                }
                handler.postDelayed(this, 1000); // Update every 1 second
            }
        };
    }
    // ... (rest of the class)
}

Modifying VideoTimer to include an auto-pause feature.

1. Set up your layout

Add a VideoView (or PlayerView for ExoPlayer) and a TextView to your activity's or fragment's layout XML.

2. Initialize media player

In your Activity or Fragment, initialize MediaPlayer or ExoPlayer and set its data source. Wait for the onPreparedListener callback.

3. Create VideoTimer instance

Once the media player is prepared, create an instance of your VideoTimer class, passing the MediaPlayer object and the TextView.

4. Start and stop the timer

Call videoTimer.startTimer() when playback begins (e.g., in onPreparedListener) and videoTimer.stopTimer() when playback pauses, stops, completes, or when the activity is paused/destroyed.

5. Handle lifecycle events

Ensure startTimer() and stopTimer() are called appropriately within your Activity or Fragment lifecycle methods (onResume(), onPause(), onDestroy()) to manage resources and prevent leaks.
