Displaying Progress Bars During AJAX Requests

Hero image for How to show progress bar while loading, using ajax

Learn how to implement a progress bar to enhance user experience during asynchronous data loading with AJAX, jQuery, and PHP.

When performing asynchronous operations like AJAX requests, users can sometimes be left wondering if anything is happening, especially with slower connections or larger data transfers. Implementing a progress bar or a loading indicator significantly improves the user experience by providing visual feedback that the system is actively working. This article will guide you through creating a simple yet effective progress bar using JavaScript (jQuery) for the frontend and PHP for the backend.

Understanding the Need for Progress Indicators

AJAX (Asynchronous JavaScript and XML) allows web pages to update asynchronously by exchanging small amounts of data with the server behind the scenes. While this improves responsiveness, it can also create a perception of delay if the user isn't aware that an operation is in progress. A progress bar or spinner addresses this by:

  • Improving User Experience: Reduces anxiety and uncertainty.
  • Providing Feedback: Informs the user that the request has been sent and is being processed.
  • Indicating Activity: Prevents users from attempting to re-submit forms or click multiple times, which can lead to duplicate requests or errors.
sequenceDiagram
    actor User
    participant Browser
    participant Server

    User->>Browser: Initiates AJAX action
    Browser->>Browser: Show Loading Indicator
    Browser->>Server: AJAX Request (data)
    Server-->>Browser: AJAX Response (data)
    Browser->>Browser: Hide Loading Indicator
    Browser->>User: Display Updated Content

Sequence diagram of an AJAX request with a loading indicator

Frontend Implementation with jQuery

On the frontend, we'll use jQuery to handle the AJAX request and manipulate the DOM to show and hide our loading indicator. The basic idea is to display the indicator before the AJAX call is made and hide it once the call completes, regardless of success or failure.

<!DOCTYPE html>
<html lang="en">
<head>
    <meta charset="UTF-8">
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <title>AJAX Progress Bar Example</title>
    <script src="https://ajax.googleapis.com/ajax/libs/jquery/3.5.1/jquery.min.js"></script>
    <style>
        #loading-indicator {
            display: none; /* Hidden by default */
            position: fixed;
            top: 50%;
            left: 50%;
            transform: translate(-50%, -50%);
            padding: 20px;
            background-color: rgba(0, 0, 0, 0.7);
            color: white;
            border-radius: 8px;
            z-index: 1000;
            font-family: Arial, sans-serif;
        }
        .spinner {
            border: 4px solid rgba(255, 255, 255, 0.3);
            border-top: 4px solid #fff;
            border-radius: 50%;
            width: 30px;
            height: 30px;
            animation: spin 1s linear infinite;
            margin: 0 auto 10px auto;
        }
        @keyframes spin {
            0% { transform: rotate(0deg); }
            100% { transform: rotate(360deg); }
        }
        #content {
            margin-top: 20px;
            padding: 15px;
            border: 1px solid #ccc;
            min-height: 100px;
        }
        button {
            padding: 10px 20px;
            font-size: 16px;
            cursor: pointer;
        }
    </style>
</head>
<body>
    <h1>AJAX Data Loader</h1>
    <button id="loadDataBtn">Load Data</button>
    <div id="content"></div>

    <div id="loading-indicator">
        <div class="spinner"></div>
        Loading data...
    </div>

    <script>
        $(document).ready(function() {
            $('#loadDataBtn').on('click', function() {
                // Show the loading indicator
                $('#loading-indicator').show();
                $('#content').html(''); // Clear previous content

                $.ajax({
                    url: 'backend.php', // Your PHP script URL
                    method: 'GET',
                    data: { delay: 3 }, // Simulate a 3-second delay
                    success: function(response) {
                        $('#content').html('<p>Data loaded successfully!</p>' + response);
                    },
                    error: function(xhr, status, error) {
                        $('#content').html('<p>Error loading data: ' + error + '</p>');
                        console.error("AJAX Error: ", status, error);
                    },
                    complete: function() {
                        // Hide the loading indicator when the request is complete
                        $('#loading-indicator').hide();
                    }
                });
            });
        });
    </script>
</body>
</html>

HTML structure with a loading indicator and jQuery AJAX call

Backend Implementation with PHP

The backend PHP script will simulate a delay to demonstrate the progress bar in action. In a real-world application, this would be where your database queries, API calls, or heavy computations would occur.

<?php
// backend.php

// Simulate a delay based on the 'delay' GET parameter
$delay = isset($_GET['delay']) ? (int)$_GET['delay'] : 1;
if ($delay > 0) {
    sleep($delay);
}

// Set content type to HTML for demonstration
header('Content-Type: text/html');

// Return some sample data
echo "<p>This content was loaded from the server after a {$delay}-second delay.</p>";
echo "<ul>";
for ($i = 1; $i <= 5; $i++) {
    echo "<li>Item {$i}</li>";
}
echo "</ul>";
?>

Simple PHP script to simulate a backend process with a delay

Putting It All Together

To see this in action, save the HTML code as index.html and the PHP code as backend.php in the same directory on a web server (e.g., Apache, Nginx with PHP-FPM). When you open index.html in your browser and click the 'Load Data' button, you will observe the 'Loading data...' indicator appear for a few seconds before the content from backend.php is displayed.
