Understanding Array Declarations in SystemVerilog

Explore the various ways to declare and initialize arrays in SystemVerilog, covering static, dynamic, associative, and queue arrays with practical examples.

Arrays are fundamental data structures in any programming language, and SystemVerilog is no exception. They allow you to store multiple values of the same data type under a single name, making it easier to manage and manipulate related data. However, SystemVerilog offers a rich set of array types, each with unique characteristics and use cases. Understanding these distinctions is crucial for efficient and effective hardware description and verification.

Static Arrays: Fixed Size and Traditional

Static arrays are the most basic form of arrays in SystemVerilog. Their size is fixed at compile time and cannot be changed during simulation. They are declared by specifying the range of indices. SystemVerilog supports both packed and unpacked arrays, which differ in how they are stored in memory and how they can be accessed.

flowchart TD
    A[Array Declaration] --> B{Static Array?}
    B -- Yes --> C[Fixed Size at Compile Time]
    C --> D{Packed or Unpacked?}
    D -- Packed --> E[Contiguous Memory, Bit-Selectable]
    D -- Unpacked --> F[Separate Memory, Element-Selectable]
    B -- No --> G[Dynamic/Associative/Queue]

Decision flow for SystemVerilog array types

// Unpacked array: elements are separate, can be of any data type
bit [7:0] my_unpacked_array [0:3]; // An array of 4 bytes

// Packed array: elements are contiguous bits, must be single-bit types
bit [3:0][7:0] my_packed_array; // A 32-bit packed array (4 bytes)

// Multi-dimensional unpacked array
int matrix [2][3]; // A 2x3 array of integers

// Initialization
int values [3] = '{10, 20, 30};
int another_matrix [2][2] = '{'{1,2}, '{3,4}};

Examples of static array declarations and initialization

Dynamic Arrays: Flexible Sizing at Runtime

Dynamic arrays provide the flexibility to change their size during simulation. This is particularly useful when the exact number of elements is not known at compile time. They are declared without a size, and their size is set using the new operator. Dynamic arrays are always one-dimensional.

// Declaration of a dynamic array
int my_dynamic_array [];

initial begin
    // Allocate space for 5 integers
    my_dynamic_array = new[5];
    $display("Dynamic array size: %0d", my_dynamic_array.size());

    // Initialize elements
    foreach (my_dynamic_array[i]) begin
        my_dynamic_array[i] = i * 10;
    end

    // Resize the array (contents are lost if new size is different)
    my_dynamic_array = new[10](my_dynamic_array); // Copy old contents
    $display("New dynamic array size: %0d", my_dynamic_array.size());

    // Delete the array
    my_dynamic_array.delete();
    $display("Dynamic array size after delete: %0d", my_dynamic_array.size());
end

Declaring and manipulating dynamic arrays

Associative Arrays: Sparse Data Storage

Associative arrays are similar to hash tables or dictionaries in other languages. They allow you to store data using non-contiguous, user-defined keys (which can be of any data type, not just integers). This makes them ideal for sparse data structures where only a few elements are populated, or when you need to map arbitrary keys to values. They consume memory only for the elements that are actually stored.

graph TD
    A[Data Element] --> B{Key: Value Pair}
    B --> C[Associative Array]
    C -- Stores --> D[Sparse Data]
    C -- Accesses by --> E[Arbitrary Key (e.g., string, int, enum)]
    E -- Maps to --> F[Value]

Conceptual model of an associative array

// Declare an associative array with string keys and integer values
int my_associative_array [string];

// Declare an associative array with integer keys and bit values
bit [7:0] register_map [int];

initial begin
    my_associative_array["apple"] = 10;
    my_associative_array["banana"] = 20;
    my_associative_array["cherry"] = 30;

    $display("Value for 'apple': %0d", my_associative_array["apple"]);

    // Check if a key exists
    if (my_associative_array.exists("banana")) begin
        $display("'banana' exists.");
    end

    // Iterate through associative array
    string key;
    $display("Associative array contents:");
    if (my_associative_array.first(key)) begin
        do begin
            $display("  Key: %s, Value: %0d", key, my_associative_array[key]);
        end while (my_associative_array.next(key));
    end

    // Delete an element
    my_associative_array.delete("banana");
end

Examples of associative array declaration and usage

Queues: Ordered, Variable-Size Collections

Queues are ordered, variable-size collections of elements, similar to a C++ std::deque or a Java LinkedList. They allow efficient insertion and deletion at both ends, making them suitable for modeling FIFOs (First-In, First-Out) or other dynamic lists. Queues are declared using [$] for an unsized queue or [min:max] for a sized queue.

// Declare an unsized queue of integers
int my_queue [$];

// Declare a sized queue (max 5 elements)
bit [7:0] fifo_buffer [$:5];

initial begin
    // Add elements to the end (push_back)
    my_queue.push_back(10);
    my_queue.push_back(20);
    my_queue.push_back(30);
    $display("Queue after push_back: %p", my_queue);

    // Add elements to the front (push_front)
    my_queue.push_front(5);
    $display("Queue after push_front: %p", my_queue);

    // Remove from front (pop_front)
    int val = my_queue.pop_front();
    $display("Popped value: %0d, Queue: %p", val, my_queue);

    // Remove from back (pop_back)
    val = my_queue.pop_back();
    $display("Popped value: %0d, Queue: %p", val, my_queue);

    // Access elements directly
    $display("First element: %0d", my_queue[0]);

    // Get size
    $display("Queue size: %0d", my_queue.size());

    // Delete all elements
    my_queue.delete();
    $display("Queue after delete: %p", my_queue);
end

Examples of queue declaration and operations
